3020 Series
D-Sub Die Cast Metal Hoods
[ U-Shape Series ]

Material:
Metal Shield: Zinc Alloy; plated bright nickel over bright copper
4-40 Fillister Head Screws and Hex Nuts: Steel; nickel plated
4-40 Mounting screws (Thumbscrews): Steel: nickel plated
Ordering Part Number
3020 - [] [] - [][] MM
Series Number Type of Screws Shell Size Cable opening Dia.

0: 4-40 Mounting screws
1: 4-40 Thumbscrews		 1: 9 Pos. (Size E)
2: 15 Pos. (Size A)
3: 19 Pos.
5: 25 Pos. (Size B)
6: 37 Pos. (Size C)
7: 44 Pos.		 See Table
Example: for 9.5mm Cable enter 9.5
See table for available sizes.

TABLE: RECOMMENDED CABLE SIZES
Shell Size:
Standard:
High Density:		 Size E
9
15		 Size A
15
26		 -
19
-		 Size B
25
44		 Size C
37
62		 -
44
-
Available
Cable Opening
Dia. (mm):		 6.0
7.0
8.0
9.5		 7.0
9.0
10.5		 7.0 8.0
9.0
10.0
11.0
13.0		 9.0
10.0
13.5
16.0		 6.0
7.0
7.6
9.0

3020-01
3020-02
3020-05
3020-06
3020-07
